PF-03a // Raised Access Floor

Calcium Sulphate: CSF Series

Full Encased CS Panel

A premium calcium sulphate core fully encased in galvanized steel — unmatched moisture resistance, high load capacity and excellent acoustic insulation for high-humidity, mission-critical and Data Centre environments.

Request Quote Brochure (PDF)

Part of the Calcium Sulphate family.

CSF Series panel above its four adjustable pedestals and fixing screws

Close-up of the fixing screw, encapsulated calcium sulphate panel and pedestal head

600 × 600 mm

Countersunk fixing screwDrops through the panel into the head

Encapsulated CS panelCalcium sulphate core sealed in steel

Pedestal head and stemLocating gasket, adjustable height

CSF Series · full encased

Hover for the fixing detail

Specifications

Panel Size600 × 600 mm

CoreHigh-strength structural calcium sulphate

EncapsulationFull steel — galvanized pan + top sheet

Fire Rating60 minutes, non-combustible

Recycled Content>50%, VOC tested

Tolerances±0.25 mm sq / ±0.5 mm flat

Key Features

Unmatched moisture resistance vs woodcore panels

Outstanding airborne sound reduction

Excellent point load and rolling load resistance

Dimensional stability in variable climates

The panel in real life

CSF Series, installedCalcium sulphate core sealed in galvanized steel — the finished panel as it arrives on site.

Calcium Sulphate: CSF Series

Specifications

Key Features

The panel in real life

Applications

Surface Finishes

Specify Calcium Sulphate: CSF Series for your project
